Cobotic Palletiser

Robotics and Drives Services have developed a Cobot Palletising Cell for the dynamic palletising of cases or boxes. There is now a huge industry for collaborative robot systems in manufacturing, handling, packing and more.

This is why RDS has developed a standard solution for cobot palletising which can be integrated into any cobotic production line. The generic design of this cell allows it to adapt to any factory requirements that are in need of such technology integration.

Our Palletising Cobot can be programmed to stack pallets with boxes or cases in any manner and any pattern required. This RDS original design can also be developed further and can handle the palletising of two pallet zones which can be of huge benefit to your production time as it cuts the downtime in half. The system can be set up to palletise one pallet zone, and when it is full and requires unloading, the cobot can continue to palletise the other pallet zone.

Having a collaborative robot cell means that the need for safety fences, light curtains or safety scanners can be eliminated, not only reducing the cost of the cell, but reducing the footprint as well.

There are endless possibilities that we can achieve with our standard solutions, and endless technologies that we can implement into these systems to improve industry.


  • Speed (Single Cases)

    Up to 6 cases per minute
  • Speed (Multiple Cases)

    Up to 20 cases per minute
  • Payload

    0.5kg - 14kg
  • Footprint

    From 2m x 2m
  • Degree of Freedom

    8 axis
  • Configuration

    1 or 2 product infeed, 1 pallet build location
  • Gripper Type

    Vacuum, clamp or grappler
  • Control System

    Allen Bradley, Siemens or Omron
  • Delivery Time

    From 4 weeks of final order
  • Cost

    From €120,000


  • Supports Multiple Conveyor Types

    Integrates with multiple conveyor types including belt, roller, and gravity conveyers.
  • Flexible Layout

    Configurable layout to adhere to factory requirements.
  • Minimal Footprint

    Robot can be inverted for zero footprint.
  • Easy to Use Software

    Touch screen HMI interface allows for easily programmed product assemblies.
  • CE Certified Safety System

    Fully integrated safety system allows for installation without the need for safety fences.
  • Multiple Gripper Options

    Choose from vacuum, clamp and grappler gripper types.
  • Fast Installation Time

    Pre-tested systems allow for fast factory installation times and minimal disruption and operational downtime.
  • Remote Diagnosis Available

    Our experienced engineers can log in remotely to diagnose any issues in an instant.
  • Easy System Integration

    Monitor the performance of your robot system through statistical feedback.


  • This cell can be adapted to any factory setting with RDS designs.
  • The cell can also be improved and upgraded to allow for a second pallet zone and more.
